导体数目 |
导体 | 絕緣 | 护套 | |||
|---|---|---|---|---|---|---|
| 面积 (mm2) | 构造 (No./mm) | 厚度 (毫米) | 外径(毫米) | 厚度 | 外径(毫米） | |
| 1 | 1.5 | 30 / 0.253 | 0.8 | 3.2 | 1.4 | 6.3 |
| 1 | 2.5 | 50 / 0.253 | 0.9 | 3.9 | 1.4 | 7 |
| 1 | 4 | 126 / 0.2 | 1 | 4.8 | 1.5 | 8.1 |
| 1 | 6 | 85 / 0.3 | 1 | 5.4 | 1.6 | 8.9 |
| 2 | 1.5 | 30 / 0.253 | 0.8 | 3.2 | 1.5 | 9.6 |
| 2 | 2.5 | 50 / 0.253 | 0.9 | 3.9 | 1.7 | 11.4 |
| 2 | 4 | 126 / 0.2 | 1 | 4.8 | 1.8 | 13.4 |
| 2 | 6 | 85 / 0.3 | 1 | 5.4 | 2 | 15 |
| 3 | 1.5 | 30 / 0.253 | 0.8 | 3.2 | 1.6 | 10.3 |
| 3 | 2.5 | 50 / 0.253 | 0.9 | 3.9 | 1.8 | 12.2 |
| 3 | 4 | 126 / 0.2 | 1 | 4.8 | 1.9 | 14.3 |
| 3 | 6 | 85 / 0.3 | 1 | 5.4 | 2.1 | 16 |
| 4 | 1.5 | 30 / 0.253 | 0.8 | 3.2 | 1.7 | 11.4 |
| 4 | 2.5 | 50 / 0.253 | 0.9 | 3.9 | 1.9 | 13.5 |
| 4 | 4 | 126 / 0.2 | 1 | 4.8 | 2 | 15.9 |
| 4 | 6 | 85 / 0.3 | 1 | 5.4 | 2.3 | 18 |
| 5 | 1.5 | 30 / 0.253 | 0.8 | 3.2 | 1.8 | 12.5 |
| 5 | 2.5 | 50 / 0.253 | 0.9 | 3.9 | 2 | 15 |
| 5 | 4 | 126 / 0.2 | 1 | 4.8 | 2.2 | 17.9 |
| 5 | 6 | 85 / 0.3 | 1 | 5.4 | 2.5 | 20 |
| 3C+1C | 3 x 2.5 + 1 x 1.5 | 50 / 0.253 + 30 / 0.253 | 0.9 / 0.8 | 3.9 / 3.2 | 2 | 13.7 |
| 3C+1C | 3 x 4.0 +1 x 2.5 | 62 / 0.287 + 50 / 0.253 | 1.0 / 0.9 | 4.8 / 3.9 | 2 | 15.9 |
| 3C+1C | 3 x 6.0 + 1 x 4.0 | 85 / 0.30 + 62 / 0.287 | 1.0 / 1.0 | 5.4 / 4.8 | 2 | 17.8 |
