Conductor |
Insulation |
Jacket |
|
AWG Size |
AWG Size |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Diam. (mm) |
Nom. Thick (mm) |
Nom. Diam. (mm) |
|
2 |
1.5 |
1 / 1.38, 7 / 0.52 |
0.7 |
2.80, 3.00 |
1.2 |
8.60, 8.90 |
|
2 |
2.5 |
1 / 1.78, 7 / 0.68 |
0.8 |
3.40, 3.70 |
1.2 |
9.80, 10.20 |
|
2 |
4 |
1 / 2.25, 7 / 0.85 |
0.8 |
3.85, 4.20 |
1.2 |
10.70, 11.20 |
|
2 |
6 |
1 / 2.76, 7 / 1.04 |
0.8 |
4.40, 4.80 |
1.2 |
11.70, 11.20 |
|
2 |
10 |
7 / 1.35 |
1 |
6.15 |
1.2 |
15.6 |
|
3 |
1.5 |
1 / 1.38, 7 / 0.52 |
0.7 |
2.80, 3.00 |
1.2 |
9.00, 9.40 |
|
3 |
2.5 |
1 / 1.78, 7 / 0.68 |
0.8 |
3.40, 3.70 |
1.2 |
10.30, 10.70 |
|
3 |
4 |
1 / 2.25, 7 / 0.85 |
0.8 |
3.85, 4.20 |
1.2 |
11.30, 11.80 |
|
3 |
6 |
1 / 2.76, 7 / 1.04 |
0.8 |
4.40, 4.80 |
1.4 |
12.80, 13.50 |
|
3 |
10 |
7 / 1.35 |
1 |
6.15 |
1.4 |
16.3 |
|
4 |
1.5 |
1 / 1.38, 7 / 0.52 |
0.7 |
2.80, 3.00 |
1.2 |
10.20, 10.70 |
|
4 |
2.5 |
1 / 1.78, 7 / 0.68 |
0.8 |
3.40, 3.85 |
1.2 |
11.60, 12.90 |
|
4 |
4 |
1 / 2.25, 7 / 0.85 |
0.8 |
3.85, 4.20 |
1.4 |
13.00, 13.90 |
|
4 |
6 |
1 / 2.76, 7 / 1.04 |
0.8 |
4.40, 4.80 |
1.4 |
14.80, 15.90 |
|
4 |
10 |
1 / 3.57, 7 / 1.35 |
1 |
5.70, 6.15 |
1.4 |
17.90, 19.00 |
|
5 |
1.5 |
1 / 1.38, 7 / 0.52 |
0.7 |
2.80, 3.00 |
1.2 |
10.90, 9.00 |
|
5 |
2.5 |
1 / 1.78, 7 / 0.68 |
0.8 |
3.40, 3.85 |
1.2 |
12.60, 13.80 |
|
5 |
4 |
1 / 2.25, 7 / 0.85 |
0.8 |
3.85, 4.20 |
1.4 |
14.60, 15.60 |
|
5 |
6 |
1 / 2.76, 7 / 1.04 |
0.8 |
4.40, 4.80 |
1.4 |
16.10, 17.20 |
|
5 |
10 |
1 / 3.57, 7 / 1.35 |
1 |
5.70, 6.15 |
1.4 |
19.60, 20.90 |
Marking:CCC A004278 60227 IEC 10 (BVV)-300 / 500V nXxx mm2 CHAU'S
