No. of Conductor |
Conductor |
Insulation |
Jacket |
|
|
Sectional Area (mm2) |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Diam. (mm) |
Nom. Thick (mm) |
Nom. Diam. (mm) |
|
2 |
4.00 |
126/0.200 |
1.00 |
4.80 |
1.20 |
12.20 |
|
2 |
6.00 |
85/0.300 |
1.00 |
5.40 |
1.30 |
13.60 |
|
3 |
4.00 |
126/0.200 |
1.00 |
4.80 |
1.20 |
12.90 |
|
3 |
6.00 |
85/0.300 |
1.00 |
5.40 |
1.30 |
14.40 |
|
4 |
4.00 |
126/0.200 |
1.00 |
4.80 |
1.20 |
14.50 |
|
4 |
6.00 |
85/0.300 |
1.00 |
5.40 |
1.30 |
16.20 |
|
5 |
4.00 |
126/0.200 |
1.00 |
4.80 |
1.20 |
16.20 |
|
5 |
6.00 |
85/0.300 |
1.00 |
5.40 |
1.30 |
18.30 |
|
6 |
0.75 |
43/0.150 |
0.60 |
2.35 |
1.00 |
9.400 |
|
6 |
1.00 |
32/0.200 |
0.60 |
2.55 |
1.10 |
10.20 |
|
6 |
1.50 |
30/0.253 |
0.80 |
3.20 |
1.20 |
12.30 |
|
6 |
2.50 |
50/0.253 |
0.90 |
3.90 |
1.40 |
14.80 |
|
6 |
4.00 |
126/0.200 |
1.00 |
4.80 |
1.50 |
17.70 |
|
6 |
6.00 |
85/0.300 |
1.00 |
5.40 |
1.70 |
19.90 |
|
3C+1C |
3x1.5+1x1.0 |
30/0.253+32/0.2 |
0.8/06 |
3.2/2.55 |
1.10 |
10.10 |
|
3C+1C |
3x2.5+1x1.5 |
50/0.253+30/0.253 |
0.9/0.8 |
3.9/3.2 |
1.20 |
12.00 |
|
3C+1C |
3x4.0+1x2.5 |
62/0.287+50/0.253 |
1.0/0.9 |
4.8/3.9 |
1.30 |
14.40 |
|
3C+1C |
3x6.0+1x4.0 |
80/0.3+62/0.287 |
1.0/1.0 |
5.4/4.8 |
1.40 |
16.10 |
Marking:CCC A004278 YZWB-300 / 500V nXxxmm2 CHAU'S CQC 2002010104011357 JB8735-98
