No. of Conductor |
Conductor |
Insulation |
Jacket |
Overall Braid |
|
|
Sectional Area (mm2) |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Diam. (mm) |
Nom. Thick (mm) |
Nom. Diam. (mm) |
Nom. Diam. (mm) |
|
2 |
0.3 |
17 / 0.15 |
0.6 |
2.05 |
0.3 |
4.5 |
5.00 |
|
2 |
0.4 |
23 / 0.15 |
0.6 |
2.1 |
0.4 |
5 |
5.50 |
|
2 |
0.5 |
29 / 0.15 |
0.6 |
2.2 |
0.4 |
5.2 |
5.70 |
|
2 |
0.75 |
43 / 0.15 |
0.6 |
2.4 |
0.4 |
5.6 |
6.10 |
|
2 |
1 |
32 / 0.20 |
0.6 |
2.55 |
0.4 |
5.9 |
6.40 |
|
2 |
1.5 |
48 / 0.20 |
0.8 |
3.2 |
0.4 |
7.4 |
7.90 |
|
2 |
2.5 |
77 / 0.20 |
0.8 |
3.65 |
0.5 |
8.8 |
9.30 |
|
2 |
4 |
126 / 0.20 |
0.8 |
4.2 |
0.5 |
9.6 |
10.10 |
|
3 |
0.3 |
17 / 0.15 |
0.6 |
1.95 |
0.4 |
4.75 |
5.25 |
|
3 |
0.4 |
23 / 0.15 |
0.6 |
2.1 |
0.4 |
5.3 |
5.80 |
|
3 |
0.5 |
29 / 0.15 |
0.6 |
2.2 |
0.4 |
5.5 |
6.00 |
|
3 |
0.75 |
43 / 0.15 |
0.6 |
2.4 |
0.4 |
5.9 |
6.40 |
|
3 |
1 |
32 / 0.20 |
0.6 |
2.55 |
0.4 |
6.25 |
6.75 |
|
3 |
1.5 |
48 / 0.20 |
0.8 |
3.2 |
0.4 |
7.7 |
8.20 |
|
3 |
2.5 |
77 / 0.20 |
0.8 |
3.65 |
0.5 |
9.2 |
9.75 |
|
3 |
4 |
126 / 0.20 |
0.8 |
4.2 |
0.5 |
10.3 |
10.80 |
Marking:CCC A004278 RXH-300/300V xx mm2 CHAU'S CQC 2002010104011358 JB8735-98
