No. of Conductor |
Conductor |
Insulation |
Shield |
Jacket |
|
|
AWG Size |
Sectional Area (mm2) |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Diam. (mm) |
|
Nom. Thick (mm) |
Nom. Diam. (mm) |
|
2 |
32 |
0.03 |
7 / 0.08 |
0.11 |
0.55 |
33/0.08 |
0.13 |
1.60 |
|
2 |
30 |
0.05 |
11 / 0.08 |
0.11 |
0.6 |
35/0.08 |
0.13 |
1.70 |
|
2 |
28 |
0.08 |
7 / 0.127 |
0.11 |
0.7 |
40/0.08 |
0.13 |
1.90 |
|
2 |
26 |
0.13 |
7 / 0.16 |
0.11 |
0.8 |
33/0.12 |
0.13 |
2.10 |
|
3 |
32 |
0.03 |
7 / 0.08 |
0.11 |
0.55 |
40/0.08 |
0.13 |
1.75 |
|
3 |
30 |
0.05 |
11 / 0.08 |
0.11 |
0.6 |
42/0.08 |
0.13 |
1.85 |
|
3 |
28 |
0.08 |
7 / 0.127 |
0.11 |
0.7 |
50/0.08 |
0.13 |
2.05 |
|
3 |
26 |
0.13 |
7 / 0.16 |
0.11 |
0.8 |
38/0.12 |
0.13 |
2.35 |
|
4 |
32 |
0.03 |
7 / 0.08 |
0.11 |
0.55 |
46/0.08 |
0.13 |
1.90 |
|
4 |
30 |
0.05 |
11 / 0.08 |
0.11 |
0.6 |
48/0.08 |
0.13 |
2.05 |
|
4 |
28 |
0.08 |
7 / 0.127 |
0.11 |
0.7 |
55/0.08 |
0.13 |
2.25 |
|
4 |
26 |
0.13 |
7 / 0.16 |
0.11 |
0.8 |
42/0.12 |
0.13 |
2.60 |
Marking:E114082 AWM 2851 xx AWG 30V 80℃ FT2 CHAU'S
