60227 IEC 53 H05VVH2-F

Standard: K60227-5/IEC60227-5

Rating: 70℃, 300 / 300V

No. of Conductor	Conductor		Insulation		Jacket
	Sectional Area (mm2)	Construction (No./mm)	Nom. Thick. (mm)	Nom. Diam. (mm)	Nom. Thick (mm)	Nom. Diam. (mm)
2	0.75	43 / 0.15	0.60	2.35	0.80	4.10 x 6.50
2	1.00	32 / 0.2	0.60	2.50	0.80	4.35 x 1.00

Marking:HU01011 - 4002A 60227 IEC53 H03VVH2-F No. 2C X Size mm2 300/300V CHAU'S YEAR
