| No. of Conductor | Conductor | Insulation | Jacket | |||
|---|---|---|---|---|---|---|
| Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) | Nom. Thick (mm) | Nom. Diam. (mm) | |
| 2 | 0.75 | 30 / 0.18 | 0.6 | 2.4 | 1 | 6.8 |
| 2 | 1.25 | 50 / 0.18 | 0.6 | 2.75 | 1 | 7.8 |
| 2 | 2 | 41 / 0.25 | 0.6 | 3.15 | 1 | 8.4 |
| 3 | 0.75 | 30 / 0.18 | 0.6 | 2.4 | 1 | 7.2 |
| 3 | 1.25 | 50 / 0.18 | 0.6 | 2.75 | 1 | 8.3 |
| 3 | 2 | 41 / 0.25 | 0.6 | 3.15 | 1 | 9.1 |
| 4 | 0.75 | 30 / 0.18 | 0.6 | 2.4 | 1 | 8 |
| 4 | 1.25 | 50 / 0.18 | 0.6 | 2.75 | 1 | 9.2 |
| 4 | 2 | 41 / 0.25 | 0.6 | 3.15 | 1 | 11 |
