Standard: JB 8735-98
Rating: 60℃, 300V / 500V
|
导体数目 |
导体 | 絕緣 | 护套 | |||
|---|---|---|---|---|---|---|
| 面积 (mm2) | 构造 (No./mm) | 厚度 (毫米) | 外径(毫米) | 厚度 | 外径(毫米） | |
| 2 | 4.00 | 126/0.200 | 1.00 | 4.80 | 1.20 | 12.20 |
| 2 | 6.00 | 85/0.300 | 1.00 | 5.40 | 1.30 | 13.60 |
| 3 | 4.00 | 126/0.200 | 1.00 | 4.80 | 1.20 | 12.90 |
| 3 | 6.00 | 85/0.300 | 1.00 | 5.40 | 1.30 | 14.40 |
| 4 | 4.00 | 126/0.200 | 1.00 | 4.80 | 1.20 | 14.50 |
| 4 | 6.00 | 85/0.300 | 1.00 | 5.40 | 1.30 | 16.20 |
| 5 | 4.00 | 126/0.200 | 1.00 | 4.80 | 1.20 | 16.20 |
| 5 | 6.00 | 85/0.300 | 1.00 | 5.40 | 1.30 | 18.30 |
| 6 | 0.75 | 43/0.150 | 0.60 | 2.35 | 1.00 | 9.400 |
| 6 | 1.00 | 32/0.200 | 0.60 | 2.55 | 1.10 | 10.20 |
| 6 | 1.50 | 30/0.253 | 0.80 | 3.20 | 1.20 | 12.30 |
| 6 | 2.50 | 50/0.253 | 0.90 | 3.90 | 1.40 | 14.80 |
| 6 | 4.00 | 126/0.200 | 1.00 | 4.80 | 1.50 | 17.70 |
| 6 | 6.00 | 85/0.300 | 1.00 | 5.40 | 1.70 | 19.90 |
| 3C+1C | 3x1.5+1x1.0 | 30/0.253+32/0.2 | 0.8/06 | 3.2/2.55 | 1.10 | 10.10 |
| 3C+1C | 3x2.5+1x1.5 | 50/0.253+30/0.253 | 0.9/0.8 | 3.9/3.2 | 1.20 | 12.00 |
| 3C+1C | 3x4.0+1x2.5 | 62/0.287+50/0.253 | 1.0/0.9 | 4.8/3.9 | 1.30 | 14.40 |
| 3C+1C | 3x6.0+1x4.0 | 80/0.3+62/0.287 | 1.0/1.0 | 5.4/4.8 | 1.40 | 16.10 |
