导体数目 |
导体 | 絕緣 | 护套 | ||||
|---|---|---|---|---|---|---|---|
| 线号 | 面积 (mm2) | 构造 (No./mm) | 厚度 (毫米) | 外径(毫米) | 厚度 | 外径(毫米） | |
| 2 | 18 | 0.824 | 41 / 0.160 | 0.76 | 2.80 | 0.76 | 7.35 |
| 2 | 16 | 1.310 | 26 / 0.253 | 0.76 | 3.10 | 0.76 | 7.95 |
| 2 | 14 | 2.080 | 41 / 0.253 | 0.76 | 3.50 | 0.76 | 8.70 |
| 2 | 12 | 3.310 | 65 / 0.253 | 0.76 | 4.00 | 1.14 | 10.50 |
| 2 | 10 | 5.260 | 104 / 0.253 | 1.14 | 5.40 | 1.52 | 14.10 |
| 3 | 18 | 0.824 | 41 / 0.160 | 0.76 | 2.80 | 0.76 | 7.80 |
| 3 | 16 | 1.310 | 26 / 0.253 | 0.76 | 3.10 | 0.76 | 8.40 |
| 3 | 14 | 2.080 | 41 / 0.253 | 0.76 | 3.50 | 0.76 | 9.30 |
| 3 | 12 | 3.310 | 65 / 0.253 | 0.76 | 4.00 | 1.14 | 11.00 |
| 3 | 10 | 5.260 | 104 / 0.253 | 1.14 | 5.40 | 1.52 | 14.80 |
| 4 | 18 | 0.824 | 41 / 0.253 | 0.76 | 2.80 | 0.76 | 8.60 |
| 4 | 16 | 1.310 | 26 / 0.253 | 0.76 | 3.10 | 0.76 | 9.20 |
| 4 | 14 | 2.080 | 41 / 0.253 | 0.76 | 3.50 | 0.76 | 10.30 |
| 4 | 12 | 3.310 | 65 / 0.253 | 0.76 | 4.00 | 1.14 | 12.10 |
| 4 | 10 | 5.260 | 104 / 0.253 | 1.14 | 5.40 | 1.52 | 16.40 |
Marking:(UL)/C(UL) E114235 SJT3/C xx AWG(xxmm2)300V 105℃ FT1 CHAU'S
Remarks:1.W Marked for outdoor use
