No. of Conductor |
Conductor |
Insulation |
Jacket |
|
|
Sectional Area (mm2) |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Diam. (mm) |
Nom. Thick (mm) |
Nom. Diam. (mm) |
|
2 |
0.75 |
43 / 0.15 |
0.6 |
2.35 |
0.8 |
6.3 |
|
2 |
1 |
32 / 0.2 |
0.6 |
2.55 |
0.8 |
6.8 |
|
2 |
1.25 |
40 / 0.2 |
0.8 |
2.9 |
0.8 |
7.4 |
|
2 |
1.5 |
30 / 0.253 |
0.7 |
3 |
0.8 |
7.8 |
|
2 |
2.5 |
50 / 0.253 |
0.8 |
3.65 |
1 |
9.3 |
|
3 |
0.75 |
43 / 0.15 |
0.6 |
2.35 |
0.8 |
7 |
|
3 |
1 |
32 / 0.2 |
0.6 |
2.55 |
0.8 |
7.2 |
|
3 |
1.25 |
40 / 0.2 |
0.8 |
3.05 |
0.8 |
8.15 |
|
3 |
1.5 |
30 / 0.253 |
0.7 |
3 |
0.9 |
8.3 |
|
3 |
2.5 |
50 / 0.253 |
0.8 |
3.65 |
1.1 |
10.1 |
Marking:H05VV-F nXxx mm2 <VDE> KMAI-KEUR CHAU'S
BSI Marking: "CHAU'S" BS 6500:2000 H05VV-F No. C Size Sq. mm IEC 60227
GOST(RUSSIA) Marking: H05VV-F 60227 IEC 53 No. C X Sq.mm 300/300V GOST
