| No. of Conductor | Conductor | Insulation | Jacket | |||
|---|---|---|---|---|---|---|
| Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) | Nom. Thick (mm) | Nom. Diam. (mm) | |
| 2 | 0.75 | 43 / 0.15 | 0.6 | 2.35 | 0.8 | 6.4 |
| 2 | 1 | 32 / 0.2 | 0.6 | 2.55 | 0.9 | 6.9 |
| 3 | 0.75 | 43 / 0.15 | 0.6 | 2.35 | 0.9 | 6.9 |
| 3 | 1 | 32 / 0.2 | 0.6 | 2.55 | 0.9 | 7.3 |
| 4 | 0.75 | 43 / 0.15 | 0.6 | 2.35 | 0.9 | 7.55 |
| 5 | 0.75 | 43 / 0.15 | 0.6 | 2.35 | 0.9 | 8.25 |
