| No. of Conductor | Conductor | Insulation | Overall Braid | ||
|---|---|---|---|---|---|
| Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) | Nom. Diam. (mm) | |
| 2 | 0.75 | 43 / 0.15 | 0.8 | 2.9 | 5.80 - 8.00 |
| 2 | 1 | 32 / 0.2 | 0.8 | 3.05 | 6.20 - 8.40 |
| 2 | 1.5 | 30 / 0.253 | 0.8 | 3.3 | 6.80 - 9.00 |
| 3 | 0.75 | 43 / 0.15 | 0.8 | 2.9 | 6.20 - 8.60 |
| 3 | 1 | 32 / 0.2 | 0.8 | 3.05 | 6.60 - 9.00 |
| 3 | 1.5 | 30 / 0.253 | 0.8 | 3.3 | 7.20 - 9.60 |
