| Conductor | Insulation | ||
|---|---|---|---|
| Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) |
| 1.5 | 1 / 1.38, 7 / 0.52 | 0.7 | 2.95, 3.20 |
| 2.5 | 1 / 1.78, 7 / 0.68 | 0.8 | 3.55, 3.90 |
| 4 | 1 / 2.25, 7 / 0.85 | 0.8 | 4.00, 4.40 |
| 6 | 1 / 2.76, 7 / 1.04 | 0.8 | 4.50, 5.10 |
| 10 | 7 / 1.35 | 1 | 6.45 |
