No. of Conductor |
Conductor |
Insulation |
Jacket |
Max Voltage (V) |
Max Temp. (℃) |
|
|
Sectional Area (mm2) |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Thick. (mm) |
Nom. Thick (mm) |
Nom. Diam. (mm) |
|
|
|
2 |
0.75 |
43 / 0.15 |
0.8 |
2.9 |
1.3 |
8.5 |
600 / 1000 |
90 |
|
2 |
1 |
32 / 0.2 |
0.8 |
3 |
1.3 |
8.8 |
600 / 1000 |
90 |
|
2 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.5 |
9.6 |
600 / 1000 |
90 |
|
2 |
2.5 |
50 / 0.253 |
0.8 |
3.9 |
1.7 |
11.4 |
600 / 1000 |
90 |
|
2 |
0.75 |
43 / 0.15 |
0.8 |
2.9 |
1.4 |
9.15 |
600 / 1000 |
90 |
|
3 |
1 |
32 / 0.2 |
0.8 |
3 |
1.4 |
9.4 |
600 / 1000 |
90 |
|
3 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.6 |
10.3 |
600 / 1000 |
90 |
|
3 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.8 |
12.2 |
600 / 1000 |
90 |
Marking:H07RN-F No. Size Sq.mm 600 / 1000V 90℃ S / 338 CHAU'S
