No. of Conductor |
Conductor |
Insulation |
Jacket |
Max Voltage (V) |
Max Temp. (℃) |
|
|
Sectional Area (mm2) |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Diam. (mm) |
Nom. Thick (mm) |
Nom. Diam. (mm) |
|
|
|
2 |
0.75 |
43 / 0.150 |
0.6 |
2.35 |
0.80 |
6.40 |
250 / 440 |
90 |
|
2 |
1.00 |
32 / 0.200 |
0.6 |
2.55 |
0.90 |
6.90 |
250 / 440 |
90 |
|
2 |
1.50 |
30 / 0.253 |
0.6 |
3.20 |
1.00 |
8.35 |
250 / 440 |
90 |
|
2 |
2.50 |
50 / 0.253 |
0.6 |
3.90 |
1.10 |
10.00 |
250 / 440 |
90 |
|
3 |
0.75 |
43 / 0.150 |
0.6 |
2.35 |
0.90 |
6.90 |
250 / 440 |
90 |
|
3 |
1.00 |
32 / 0.200 |
0.6 |
2.55 |
0.90 |
7.30 |
250 / 440 |
90 |
|
3 |
1.50 |
30 / 0.253 |
0.8 |
3.20 |
1.00 |
8.80 |
250 / 440 |
90 |
|
3 |
2.50 |
50 / 0.253 |
0.9 |
3.90 |
1.10 |
10.50 |
250 / 440 |
90 |
Marking:HO5RR-F No. Size Sq.mm 250 / 440V 90℃ S / 338 CHAU'S
