| No. of Conductor | Conductor | Insulation | Jacket | Max Voltage (V) | Amp. Rating | Max Temp. (℃) | |||
|---|---|---|---|---|---|---|---|---|---|
| Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Thick. (mm) | Nom. Thick (mm) | Nom. Diam. (mm) | ||||
| 2 | 0.75 | 43 / 0.15 | 0.6 | 0.35 | 0.8 | 4.05 x 6.40 | 250 / 440 | 7.5A | 75 / 90 |
