Approval No.: S / 338
Standard: AS / NZS 3191
| No. of Conductor | Conductor | Insulation | Jacket | Max Voltage (V) | Amp. Rating | Max Temp. (℃) | |||
|---|---|---|---|---|---|---|---|---|---|
| Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Thick. (mm) | Nom. Thick (mm) | Nom. Diam. (mm) | ||||
| 2 | 0.50 | 29 / 0.15 | 0.50 | 1.95 | 0.60 | 3.20 x 5.20 | 250 / 250 | - | 75 / 90 |
| 2 | 0.75 | 43 / 0.15 | 0.50 | 2.15 | 0.60 | 3.40 x 5.50 | 2580 / 250 | 7.5A | 75 / 90 |
