Rating : 105℃, 300V
Application:
Internal Wiring For External Interconnection Equipment
Standard: UL 758
| No. of Conductor | Conductor | Insulation | Jacket | ||||
|---|---|---|---|---|---|---|---|
| AWG Size | Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) | Nom. Thick (mm) | Nom. Diam. (mm) | |
| 2 | 18 | 0.824 | 41/0.160 | 0.38 | 2.0 | 0.76 | 3.6x5.7 |
| 2 | 16 | 1.310 | 26/0.253 | 0.38 | 2.3 | 0.76 | 3.9x6.3 |
| 3 | 18 | 0.824 | 41/0.160 | 0.38 | 2.0 | 0.76 | 3.6x7.7 |
| 3 | 16 | 1.310 | 26/0.253 | 0.38 | 2.3 | 0.76 | 3.9x8.6 |
