Rating: 90℃, 300V
Application:
Internal Wiring For Electrical Appliances
Standard: UL 62
| No. of Conductor | Conductor | Insulation | |||
|---|---|---|---|---|---|
| AWG Size | Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) | |
| 2 | 20 | 0.519 | 21 / 0.180 | 1.14 | 3.35 x 6.10 |
| 2 | 18 | 0.824 | 41 / 0.160 | 1.14 | 3.50 x 6.95 |
| 2 | 16 | 1.310 | 26 / 0.253 | 1.14 | 3.75 x 7.55 |
| 3 | 20 | 0.519 | 21 / 0.180 | 1.14 | 3.35 x 9.45 |
| 3 | 18 | 0.824 | 41 / 0.160 | 1.14 | 3.50 x 10.20 |
| 3 | 16 | 1.320 | 26 / 0.253 | 1.14 | 3.75 x 11.10 |
