Rating:
60℃ / 105℃, 300V
3-Wire with Green Grounding Conductor
Application:
For Refrigerators or Air Conditioners
Standard:
UL62 / C22.2 No.49
No. of Conductor | Conductor | Insulation | Jacket | ||||
---|---|---|---|---|---|---|---|
AWG Size | Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) | Nom. Thick (mm) | Nom. Diam. (mm) | |
2 | 18 | 0.824 | 41 / 0.16 | - | - | 1.52 | 4.2 x 8.4 |
2 | 16 | 1.310 | 26 / 0.253 | - | - | 1.52 | 4.5 x 9.0 |
2 | 14 | 2.080 | 41 / 0.253 | - | - | 2.03 | 5.8 x 12.0 |
2 | 12 | 3.310 | 65 / 0.253 | - | - | 2.41 | 7.0 x 14.0 |
3 | 18 | 0.824 | 41 / 0.16 | 0.38 | 2.15 | 1.52 | 4.3 x 11.4 |
3 | 16 | 1.310 | 26 / 0.253 | 0.38 | 2.40 | 1.52 | 4.5 x 12.2 |
3 | 14 | 2.080 | 41 / 0.253 | 0.38 | 2.80 | 2.03 | 5.8 x 14.8 |
3 | 12 | 3.310 | 65 / 0.253 | 0.38 | 3.35 | 2.41 | 7.0 x 16.8 |
