Rating:
60℃ / 105℃, 300V
3-Wire with Green Grounding Conductor
Application:
Same as NISPT-1 but Heavier Constructor
CSA only for two Conductor Type
Standard:
UL62 / C22.2 No.49
| No. of Conductor | Conductor | Insulation | Jacket | ||||
|---|---|---|---|---|---|---|---|
| AWG Size | Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) | Nom. Thick (mm) | Nom. Diam. (mm) | |
| 2 | 18 | 0.824 | 41 / 0.160 | 0.76 | 2.8 | 0.38 | 4.05 x 7.50 |
| 2 | 16 | 1.310 | 26 / 0.253 | 0.76 | 3.1 | 0.38 | 4.35 x 8.20 |
| 3 | 18 | 0.824 | 41 / 0.160 | 0.76 | 2.8 | 0.38 | 4.05x11.10 |
| 3 | 16 | 1.310 | 26 / 0.253 | 0.76 | 3.1 | 0.38 | 4.35x12.00 |
