Rating:
60℃ / 105℃, 300V
3-Wire with Green Grounding Conductor
Application:
Light Duty Cord for Pendant or Portable Use
Standard:
UL62
| No. of Conductor | Conductor | Insulation | Jacket | ||||
|---|---|---|---|---|---|---|---|
| AWG Size | Sectional Area (mm2) | Construction (No./mm) | Nom. Thick. (mm) | Nom. Diam. (mm) | Nom. Thick (mm) | Nom. Diam. (mm) | |
| 2 | 20 | 0.52 | 21 / 0.18 | 0.38 | 1.85 | 0.38 | 2.70 x 4.95 |
| 2 | 18 | 0.82 | 41 / 0.16 | 0.38 | 2.15 | 0.38 | 3.25 x 6.00 |
| 2 | 20 | 0.52 | 21 / 0.18 | 0.38 | 1.85 | 0.38 | 2.70 x 7.50 |
| 2 | 18 | 0.82 | 41 / 0.16 | 0.38 | 2.15 | 0.38 | 3.25 x 8.50 |
