No. of Conductor |
Conductor |
Insulation |
Jacket |
|
|
Sectional Area (mm2) |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Diam. (mm) |
Nom. Thick (mm) |
Nom. Diam. (mm) |
|
1 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.4 |
6.3 |
|
1 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.4 |
7 |
|
1 |
4 |
126 / 0.2 |
1 |
4.8 |
1.5 |
8.1 |
|
1 |
6 |
85 / 0.3 |
1 |
5.4 |
1.6 |
8.9 |
|
2 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.5 |
9.6 |
|
2 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.7 |
11.4 |
|
2 |
4 |
126 / 0.2 |
1 |
4.8 |
1.8 |
13.4 |
|
2 |
6 |
85 / 0.3 |
1 |
5.4 |
2 |
15 |
|
3 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.6 |
10.3 |
|
3 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.8 |
12.2 |
|
3 |
4 |
126 / 0.2 |
1 |
4.8 |
1.9 |
14.3 |
|
3 |
6 |
85 / 0.3 |
1 |
5.4 |
2.1 |
16 |
|
4 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.7 |
11.4 |
|
4 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.9 |
13.5 |
|
4 |
4 |
126 / 0.2 |
1 |
4.8 |
2 |
15.9 |
|
4 |
6 |
85 / 0.3 |
1 |
5.4 |
2.3 |
18 |
|
5 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.8 |
12.5 |
|
5 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
2 |
15 |
|
5 |
4 |
126 / 0.2 |
1 |
4.8 |
2.2 |
17.9 |
|
5 |
6 |
85 / 0.3 |
1 |
5.4 |
2.5 |
20 |
|
3C+1C |
3 x 2.5 + 1 x 1.5 |
50 / 0.253 + 30 / 0.253 |
0.9 / 0.8 |
3.9 / 3.2 |
2 |
13.7 |
|
3C+1C |
3 x 4.0 +1 x 2.5 |
62 / 0.287 + 50 / 0.253 |
1.0 / 0.9 |
4.8 / 3.9 |
2 |
15.9 |
|
3C+1C |
3 x 6.0 + 1 x 4.0 |
85 / 0.30 + 62 / 0.287 |
1.0 / 1.0 |
5.4 / 4.8 |
2 |
17.8 |
Marking:CCC A004278 YCW-450/750V nXxx+1Xxx mm2 CHAU'S CQC 2002010104011357 JB8735-98
