No. of Conductor |
Conductor |
Insulation |
Jacket |
|
|
Sectional Area (mm2) |
Construction (No./mm) |
Nom. Thick. (mm) |
Nom. Diam. (mm) |
Nom. Thick (mm) |
Nom. Diam. (mm) |
|
1 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.4 |
6.3 |
|
1 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.4 |
7 |
|
1 |
4 |
126 / 0.2 |
1 |
4.8 |
1.5 |
8.1 |
|
1 |
6 |
85 / 0.3 |
1 |
5.4 |
1.6 |
8.9 |
|
2 |
1 |
32 / 0.2 |
0.8 |
3 |
1.3 |
8.8 |
|
2 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.5 |
9.6 |
|
2 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.7 |
11.4 |
|
2 |
4 |
126 / 0.2 |
1 |
4.8 |
1.8 |
13.4 |
|
2 |
6 |
85 / 0.3 |
1 |
5.4 |
2 |
15 |
|
3 |
1 |
32 / 0.2 |
0.8 |
3 |
1.4 |
9.4 |
|
3 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.6 |
10.3 |
|
3 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.8 |
12.2 |
|
3 |
4 |
126 / 0.2 |
1 |
4.8 |
1.9 |
14.3 |
|
3 |
6 |
85 / 0.3 |
1 |
5.4 |
2.1 |
16 |
|
4 |
1 |
32 / 0.2 |
0.8 |
3 |
1.5 |
10.5 |
|
4 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.7 |
11.4 |
|
4 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
1.9 |
13.5 |
|
4 |
4 |
126 / 0.2 |
1 |
4.8 |
2 |
15.9 |
|
4 |
6 |
85 / 0.3 |
1 |
5.4 |
2.3 |
18 |
|
5 |
1 |
32 / 0.2 |
0.8 |
3 |
1.6 |
11.6 |
|
5 |
1.5 |
30 / 0.253 |
0.8 |
3.2 |
1.8 |
12.5 |
|
5 |
2.5 |
50 / 0.253 |
0.9 |
3.9 |
2 |
15 |
|
5 |
4 |
126 / 0.2 |
1 |
4.8 |
2.2 |
17.9 |
|
5 |
6 |
85 / 0.3 |
1 |
5.4 |
2.5 |
20 |
Marking:CCC A004278 60245 IEC 66 (YCW)-450 / 750V nXxx mm2 CHAU'S
