Insulation Resistance 10MΩ

Dielectric Withstanding Voltage 1000 volts rms, 60Hz

Contact Resistance 20MΩ

Current Rating 1 1/2 amps

Retention 76N (17 lbs) between the JACK and PLUG

Crimp Tensile Strength 2.27 kg (5.0 lbs)

Mating Force 500 grams for 4 wire lead 750 grams for 6 wire lead 900 garms for 8 wire lead



MATERIAL:

Housing: ABS (94V-0)

Leads: AWG 26 compose of 7 strands tinned copper wire

Contact: 0.45mm (0.018') diameter phosphor bronze alloy

Plating: 15 micro inch minimum hard gold over nickel (30 or 50 micro inch minimum hard gold over nickel)
